BASIC INFO
Model | Capacity | Input | Output | Dimmesion(D*W*H)mm |
AGS-15 | 15KVA | 304~450V | 380V | 680×360×550 |
AGS-20 | 20KVA | 304~450V | 380V | 680×360×550 |
AGS-30 | 30KVA | 304~450V | 380V | 680×360×550 |
AGS-50 | 50KVA | 304~450V | 380V | 680×400×880 |
AGS-60 | 60KVA | 304~450V | 380V | 680×400×880 |
Capacity: | 3 Phase:6KVA~1000KVA | |||
Input Voltage | 3 Phase | 380V + 15% | ||
Output Voltage: | 3 Phase: 380V | |||
Stabilization Accuracy: | ±1.5% | |||
Efficiency: | ≥99% | |||
Frequency: | 45~65Hz | |||
Reaction Speed: | <20ms | |||
Stabilization Speed: | 30ms | |||
Insulation Class: | E | |||
Insulation Resistance: | >5MΩ | |||
Insulation Strength: | 2500V/1min | |||
Output Waveform: | No Change | |||
Working Manner: | Long-runnig | |||
Display: | Digital LCD | |||
Protection: | Overload,overvoltage,undervoltage,short circuit,default phase | |||
Heat Dissipation: | Cooling Fan |
